Mini Electric Thermal Imaging Shutter High Durability for Infrared Camera Application

Model Number : 01-002-219

Opening size : 15.5mm x 13.5mm

PITCH : PITCH=0.35mm,6PIN

Price : $22 / piece

Speed : 100ms

FPC : Yes

Delivery Time : 1-4WEEKS

Connector : BM23FR0.6-6DP-0.35V

Brand Name : CCHT

Dimensions : 26mm x 26mm x 3.15mm

Payment Terms : T/T

Durability : 500 000CS Min

Packaging Details : CARTON

Blade Q'ty : 4 pcs

Place of Origin : Sichuan, China

Drive voltage : 3.3DCV

MOQ : 100 pieces

Action mode : Bistable

Contact Now

Mini Electric Thermal Imaging Shutter High Durability for Infrared Camera Application

Technical Description

High-Torque Metal Blade Design: Features 4 pieces of durable metal blades for robust optical path control, providing superior stability and resistance to thermal drift compared to standard plastic shutters.
Bistable Electromagnetic Actuation: Utilizes a bistable mechanism that maintains its open or closed position without continuous power consumption, ensuring energy efficiency and instant response times.
Compact Square Industrial Housing: Housed in a sturdy plastic enclosure measuring 26×26×3.15 mm, designed to fit seamlessly into standardized thermal camera modules while providing effective heat dissipation.
Simplified Low-Voltage Integration: Operates on a standard 3.3V DC supply and features a straightforward 6PIN connection, minimizing design complexity for engineers integrating it into night vision or thermometry systems.

Product Usage

Night Vision Devices: Essential component in advanced night vision goggles and viewing devices for performing Non-Uniformity Correction (NUC), ensuring clear, distortion-free thermal imagery in complete darkness.
Handheld IR Thermometers: Integrated into portable thermal cameras and spot thermometers to automatically calibrate sensor arrays, compensating for ambient temperature changes to deliver precise temperature readings.
Surveillance & Security Systems: Used in fixed thermal security cameras to maintain long-term image accuracy and reliability, automatically correcting for sensor drift caused by extended exposure to varying weather conditions.

Mini Electric Thermal Imaging Shutter High Durability for Infrared Camera Application

Company Introduction

Chengdu Century Huasha Trading Co., Ltd. (CCHT) is located in Chengdu, the largest and most developed city in southwest China.

CCHT is a professional supplier of micro drive module, lens, camera module, and related components.

CCHT supplies 1000+ products, services 100+ customers and exports to 40+ countries worldwide.

Packing & Delivery

Inner package: plastic tray.
Out package: carton
High-quality packaging can effectively guarantee the perfect arrival of goods.

Mini Electric Thermal Imaging Shutter High Durability for Infrared Camera Application

FAQ

Q:Could you design and customize to meet my special requirement?
A: Yes.

Q: What about the payment method?
A: Credit card, T/T (ie. wire transfer) are acceptable.

Q: What about the shipment method?
A: Shipment by air or via express can help you to get the goods promptly.

Q: What about shipment charge?
A: Freight collect is preferred if you have any account of DHL, FedEx or UPS. If not, you can chose any of them.

Q: What's the lead time?
A: It's about 2~4 weeks, depending on the quantity.

Q: What's the warranty period?
A: Normally, it's one year from the delivered date.
